Fresnel Tungsten Spot Lights for Video/Film/Broadcast/Studio/Podcast

• Similar as Arri style fresnel spot light, equips hmi lamp, high power and brightness. This light is very suitable for the video, studio, TV, and other professional places.

Features

• High power, high brightness;

• Easy install, and easy replace the bulb;

• High CRI, suitable for video taking.

Technical Specifications

Light Sources

• Bulb: 1pc 1000W Lamp CP71, BP/1000W Lamp CP40, MP

• Base: GY9.5

• Average lifespan of lamp: 5000h

• Color: warm white, 3200K

Optics

• Dimmer: 0-100% linear dimmer

• Lens: ¢130mm

• Beam angle: 15-60degree

Light Output

• Distance: 3m, 4m, 5m

• Condensed light: 0.6m, 0.8m, 1m

• Middle light: 1.6m, 2.1m, 2.7m

• Astigmatism: 3.1m, 4.2m, 5.2m

Control

• Control mode: manual

• Control panel: switch, rotary knob

Power Supply

• Related voltage: AC110V/220V, 50/60Hz

• Related power: 1000W

Construction

• Body dimension: D266*W300*H260mm(not included handle, handle length: 290mm)

• Net weight: 6kg

• Shell color: sliver and blue

• Shell material: aluminium

Working Environment

• Working temperature: -25-40℃

• Cooling: the light body dissipates heat naturally

• Protection rating: IP20

Standard Configuration Spare Part List

• Cable: 1pc power cable with plug(America standard, Euro standard, or other standard)

Optional Configuration Spare Parts List

• Dimmer: 1pc dimmer cable

• Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

• Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

• Carton board box package size: 420*350*340(1pc/carton) (c:19-11-19)

• N.W/G.W/V.W: 5kg/6kg/10kg

• Carton board box package size: 680*360*400(4pc/carton) (c:19-10-12)

• N.W/G.W/V.W: 24kg/48kg/78.4kg

• Flight case package size: 720*690*410(4pc/case) (yg:18-12-17)

• N.W/G.W/V.W: 24kg/51kg/41kg

Selling Maintain Spare Parts List

• Switching power supply: VG-FL1000-P

• Lamp: VG-FL1000-L

• Drive board: VG-FL1000-M
